Catalog Number: KF1013

Introduction

The Affinity Biosciences FITC Annexin V Apoptosis Detection Kit with 7-AAD contains the reagents needed identify apoptotic or necrotic

cells by flow cytometry.

Kit Components

Components

Size

FITC Annexin V

25/100 tests

7-AAD

200 tests

Annexin V Binding Buffer (1X)

50 ml

FITC Annexin V

PRODUCT INFORMATION

Concentration: 5µl/test

Use By: 12 months from date of receipt

Storage Conditions: 2-8°C protected from light

Formulation: 10 mM HEPES, 140 mM NaCl, 1mM EDTA,

0.09% NaN3 pH7.4

DESCRIPTION

Annexin V belongs to the annexin family of calcium-dependent phospholipid binding proteins and has a high affinity for phosphatidylserine (PS).

One of the characteristic features of early stage apoptosis is the translocation of PS from the inner to the outer leaflet of the plasma membrane,

exposing it to the extracellular environment where it can be detected. Fluorochrome conjugated Annexin V can serve as a sensitive detection

probe for this hallmark of early stage apoptotic change.

Annexin V is generally used in combination with a viability dye, such as 7-AAD or propidium iodide (PI), that cannot pass through intact

cellular membranes. Translocation of PS occurs prior to loss of membrane integrity, therefore viability dyes would be excluded from the cell.

As cells progress through the apoptotic process, membranes are compromised and the viability dyes are able to enter the cell. Using

this method, cells that are Annexin V positive and viability dye negative are in early apoptosis. If cells are positive for both Annexin V

and the viability dye, they are either undergoing apoptotic death or necrosis. When negative for both markers, cells are viable.

PREPARATION & STORAGE

Annexin V was conjugated under optimal conditions, with unreacted dye removed from the preparation. It is recommended to store the

product undiluted at 4°C, and protected from prolonged exposure to light. Do not freeze.

APPLICATION NOTES

This Annexin V preparation has been pre-titrated and quality-tested for flow cytometry using mouse thymocytes cultured overnight in the

presence of dexamethasone to induce apoptosis. The Annexin V conjugate has been diluted for use at 5 uL per test, defined as the amount

of protein that will stain a cell sample in a final volume of approximately 100 uL. The number of cells within a sample should be determined

empirically, but typically ranges between 1x10e5 to 1x10e7 cells.

7-AAD

PRODUCT INFORMATION

Excitation Laser Blue (488 nm), Green (532 nm), Yellow-Green (561 nm)

Emission (nm): 647

Formulation: 10 mM NaH2PO4, 150 mM NaCl, 0.09% NaN3, pH 7.2

Storage Conditions: 2-8°C protected from light

Use by: 12 months from date of receipt

DESCRIPTION

7-AAD (7-Aminoactinomycin D) is a nucleic acid dye that can be used to exclude nonviable cells from the analysis of flow cytometry data.

PREPARATION & STORAGE

7-AAD is provided in solution and should be stored at 2-8°C and protected from light. Do not freeze. CAUTION: 7-AAD is a potential carcinogen.

Protect skin and eyes by wearing suitable protective clothing, gloves and eye/face protection.

APPLICATION NOTES

7-AAD is useful as a viability probe for exclusion of nonviable cells based on light scatter and fluorescence properties. It is recommend- ed to use

5 uL (0.25 ug) of 7-AAD solution per sample and incubate for 5-10 minutes in the dark prior to data acquisition.

Annexin V Binding Buffer (1X)

PRODUCT INFORMATION

Contents: Annexin V Binding Buffer (1X)

Use By: 6 months from date of receipt

Storage Conditions: 2-8°C

Formulation: Annexin V Binding Buffer (1X) contains HEPES, NaCl and CaCl2.

DESCRIPTION

Annexin V Binding Buffer is formulated to facilitate the binding of Annexin V conjugates to phosphatidylserine for subsequent analysis by flow

cytometry. This buffer is supplied as a 1X solution and requires no manipulation prior to use.

PREPARATION & STORAGE

Annexin V Binding Buffer (1X) is supplied as a 1X solution and requires no manipulation prior to use.

APPLICATION NOTES

Annexin V Binding Buffer (1X) is recommended for use with Annexin V reagents. Cells should be resuspended in Annexin V Binding Buffer

(1X) prior to incubation with Annexin V reagents.
